CT-1650
Wide Cut-to-Length Line
MODEL CT-1650
300-1650mm CTL Machine for Wider Sheet Programs
Technical Drawings & 3D Models
Wide CTL leveling, shearing, stacking, and installation handoff
Technical Specifications
Model CT-1650
Thickness 0.3mm-3.0mm | 1.5mm-6mm | 2mm-8mm | 4mm-12mm
Speed 1-80m/min
Working Size 300mm-1650mm
Weight 10t-35t (Customizable)
Total Power 294.5KW
Key Features & Benefits
300-1650 mm CTL platform for wider flat sheets and blanks
Leveling, NC length control, servo feeding, precision shearing, and stacking
Service-center sheets, fabrication panels, appliance panels, and enclosures
Flatness, length accuracy, shear timing, surface marks, and stack release records
Carbon steel, stainless, aluminum, galvanized, and coated sheet support
Wider CTL capacity for mixed-width sheet programs beyond CT-1350
Safety zone, installation space, operator handoff, and FAT/SAT acceptance records
