CT-850
Compact Cut-to-Length Line
MODEL CT-850
300-820mm CTL Machine for Small Blank Programs
Technical Drawings & 3D Models
Compact leveling, shearing, stacking, and sheet acceptance
Technical Specifications
Model CT-850
Thickness 0.3mm-3.0mm | 1.5mm-6mm | 2mm-8mm | 4mm-12mm
Speed 1-60m/min
Working Size 300-820mm
Weight 10t-35t (Customizable)
Total Power 93KW
Key Features & Benefits
300-820 mm compact CTL platform for flat sheets and small blanks
Leveling, NC length control, servo feeding, shearing, conveying, and stacking
HVAC panels, appliance skins, fabrication blanks, and compact service programs
Flatness, length tolerance, squareness, shear edge, and stack records
Carbon steel, stainless, aluminum, galvanized, and coated sheet support
Compact CTL footprint for plants that do not need wider 1350 or 1650 output
Safety stops, surface protection, operator handoff, and FAT/SAT records
